Product Description
Which Width Is Right for Your 277C?
- Factory-installed width on most 277Cs
- Best for hard surfaces: concrete, asphalt, packed gravel
- SKU: 18X4CX51A-CR277C
- Reduces psi → less lawn & turf damage
- Ideal for soft/wet ground, mud, landscaping work
- SKU: 20X4CX51A-CR277C
About the Bar Tread Pattern
The Bar (Multi-Bar) pattern maximizes ground contact area, giving a stable, even footprint on flat terrain. The continuous bar design distributes weight across a larger surface than lug patterns, which improves stability during lifting and loading on firm, level ground. A good fit for warehouse yards, paved lots, and flat jobsites.
Know Your Machine: Caterpillar 277C Undercarriage Facts
The 277C is a radial-lift Caterpillar compact track loader with a 3,200 lb rated operating capacity and 2 available track widths — 460mm (18.1") and 510mm (20.1"). At approximately 9,495 lbs operating weight, it delivers strong pushing and lifting performance.
What's Inside the Track
| Component | Specification | Why It Matters |
|---|---|---|
| Iron Cores | Drop-forged steel embeds · pitch-spaced | Maintain track shape |
| Steel Cords | Acid-washed · continuous cord layer | Prevent stretching |
| Rubber Compound | Wear-resistant · premium bonding agent | Protects cords |
| Bar Tread | Continuous bar design | Stable on flat surfaces. |
| Lug Height | ~1" nominal new depth | Replace when worn below ⅓ |
Track Dimensions
| Size | Width | Pitch | Links | SKU |
|---|---|---|---|---|
| 460mm Width | 460mm (18") | 101.6mm | 51 | 18X4CX51A-CR277C |
| 510mm Width | 510mm (20") | 101.6mm | 51 | 20X4CX51A-CR277C |
